Strong lifting performance

The maximum lifting torque of the basic arm is 920t.m;

The maximum lifting load of the fully extended main arm is 90.1m and is 11.5t;

 It can meet the installation requirements of 125m high-voltage line towers.

The whole machine is equipped with high-end configuration

8-section 90.1m double-side pin main boom, strong anti-lateral bending ability for high-altitude operation;

Equipped with double variable-bore cylinders, more powerful lifting and more stable long-arm lifting;

Onboard Cummins B6.7 non-road IV engine, powerful and reliable;

Chassis Yuchai K13 National VI engine + FAST 12-speed automatic transmission (with hydraulic buffer).

Excellent driving ability

The vehicle length is 17.6m, the shortest six-bridge product, and the minimum passing circle radius is equivalent to the five-bridge vehicle in the industry;

Balanced axle load, 445 large tires, and a full-arm driving speed of 80km/h, which is more than 25% faster than the industry.

Extremely convenient operation

Self-loading and unloading sliding variable counterweight, strong adaptability to narrow sites, convenient and safe operation;

Equipped with a two-in-one remote control, simple and time-saving operation.

Universal design saves more money

Jib universal 350t-500t series products;

Superlift universal 240t-900t series products;

Hook universal 350t-900t series products;

Standard counterweight universal 400t-2400t series products.
